IoT Bluetooth® Battery sensor for voltage monitoring
(A22722)
Position sensor with two functions. On the one hand the theft protection, on the other hand the anchor alarm.
Availability on request
Highlights
- The sensor simply needs to be connected to the on-board battery
- Small size
- Light weight
- Easy to attach using double-sided adhesive tape
Function
The position sensor has 2 functionalities.
Firstly, theft protection. You will receive an alarm on the app as soon as the defined position is left. This functionality is optimized for low power consumption on the vehicle electrical system, such as it is needed in winter storage for example.
On the other hand, the anchor alarm. As soon as your boat leaves a range that can be defined in the app, you will receive an alarm. This functionality is designed to be extremely up-to-date and quick.
Technical data
General
- Dimensions (L/W/H): 50 x 50 x 20 mm
- Weight: 27 grams
- Operating temperature range: -20° Celsius to +70° Celsius
- Storage temperature range: -40° Celsius to +70° Celsius
Power supply
-
On-board power supply/on-board battery (9V DC – 32V DC)
Bluetooth® Low Energy
- Frequency band: 2.400 – 2.4835 GHz
- Supported modes: Bluetooth® 5.0
